ATEN KX9970FR KVM extender Receiver

Product code: KX9970FR
  • ATEN KX9970FR
  • Receiver
  • Wired
  • 5120 x 2880 pixels
  • 144 Hz
  • OSD
  • Push-buttons
  • 5120 x 2880 @ 30 Hz
  • 5120 x 1440 @ 60 Hz
  • 4096 x 2160 @ 60 Hz (4:4:4)
  • 2560 x 1440 @ 144 Hz
  • 1920...

ATEN KX9970FR KVM extender Receiver

Product code Alt: KX9970FR
ATEN KX9970FR KVM extender Receiver

Product Description

The KX9970FR 5K DisplayPort KVM over IP receiver is a high performance IP- based Single Display receiver, where the transmitter can transmit a computer’s keyboard, video, mouse, and USB signals to the receiver for providing separate console accesses from both the transmitter’s and receiver’s locations. The setup allows extended access to computer systems via a USB console (USB keyboard, USB mouse, DisplayPort monitor) over Intranet, enabling users to place the computers in secure and temperature-controlled environments, which may be isolated from the user workstation.

The KX9970FR support one DisplayPort video display for delivering video resolutions of up to 5K (5120 x 2880 @ 30 Hz), and offer flawless and lossless video quality with extremely low latency. KX9970FR is equipped with two SFP+ slots. 10-Gbps SFP+ fiber module expansions are supported for fiber optic network connections and a transmission distance of up to 10 km. For connection flexibility, both the KX9970F transmitter and receiver models can be connected either directly to each other or via a high-speed network over a copper-based or fiber-based LAN. The KX9970FR also features dual power supply capability for power redundancy to ensure reliable services. The KX9970FR can be set up at the workstation, mounted onto a wall or at the rear of a rack with its space-saving 0U rack-mount design.

As an IP-based matrix extender, the KX9970FR can be installed in flexible configurations, including point to point, point to multipoint, multipoint to point, and multipoint to multipoint. When combined with the KVM over IP Matrix Manager (CCKM), it can be integrated into a KVM over IP matrix system (multipoint-to-multipoint) for providing more flexible applications in different working environments.

By integrating CCKM with KX9970FR, IT administrators can benefit from advanced features such as auto detection of all KX9970FR devices on the same subnet for the sake of fast installation or configuration, username / password authentication and authorization, and the ability to define different types of connections that can be switched and shared. Security features of the KX9970FR include 256-bit AES encryption for secured data transmissions, as well as RADIUS, LDAP, Active Directory, TACACS+ for 3rd-party authentication services. In conclusion, the KX9970FR is the most cost-effective and convenient way to provide full digital extension for control room applications through a network.

Note: *The SFP+ module (2A-141G / 2A-142G) is sold separately. Contact your ATEN dealer for product information.

Features

  • Native DP signal processing with color depth up to 12 bits
  • Lossless video compression up to True 4K, 5K with zero latency
  • Support 32:9 ultra-wide resolution
  • USB isochronous transfer enables USB camera and USB speaker usage between transmitter and receiver
    •

    Specifications

    Features
    Type
    Receiver
    Connectivity technology
    Wired
